| Shape: | Spheres | Material: | Polypropylene |
|---|---|---|---|
| Package: | 10000pcs/Plastic Bag, Wooden Pallet With Wrapped. | Classification: | Floating Ball Filler |
| HS Code: | 3926909090 | Type: | Cosmetic Packaging |
| Origin: | China | Size: | 6mm, 8mm, 10mm, 12mm, 16mm, 19mm, 20mm, 25mm |
| Color: | Translucent | ||
| Highlight: | hollow plastic spheres,hollow plastic balls |
||
Plastic Bottle with Roll on Balls Cosmetic Medical Spheres 30ml 50ml 70ml
SPECIFICATIONS:
| Physical & Chemical properties | |||||||
| Performance/Material | PE | PP | RPP | PVC | CPVC | PVDF | |
| Density (g/cm3) | 0.94-0.96 | 0.89-0.91 | 0.93-0.94 | 1.32-1.44 | 1.50-1.54 | 1.75-1.78 | |
| Operation Temp. (Centigrade) | 90 | > 100 | > 120 | > 60 | > 90 | > 150 | |
| Chemical corrosion resistance | Good | Good | Good | Good | Good | Good | |
| Compression Strength (Mpa) | > 6.0 | > 6.5 | > 7.0 | > 6.0 | > 8.0 | > 10.0 | |
| Technical data | |||||||
| Spec. (mm) | Surface area (m 2 /m 3 ) | Free volume (%) | Bulk density (kg/m 3 ) | Number per m 3 | |||
| Dia. 10 *0.6 | 325 | 40 | 357 | 1190000 | |||
| Dia. 20 *0.8 | 250 | 40 | 158 | 144000 | |||
| Dia. 25 *1.0 | 200 | 40 | 125 | 74000 | |||
| Dia. 38 *1.2 | 150 | 40 | 121 | 21000 | |||
| Dia. 46 *1.2 | 135 | 40 | 105 | 12300 | |||
| Dia. 50 *1.5 | 120 | 40 | 73 | 10480 | |||
| Note: The above data are reference to material PP | |||||||
| Ball Diameter and Surface Coverage | |||||||
| Spec. (mm) | Average Weight (g) | Number per ft2 | Number per m2 | ||||
| Dia. 10 | 0.25 | 1076 | 11600 | ||||
| Dia. 19 | 1.0 | 270 | 2900 | ||||
| Dia. 25 | 1.5 | 172 | 1850 | ||||
| Dia. 38 | 4.5 | 74 | 800 | ||||
| Dia. 50 | 8.0 | 43 | 465 |
||||
DESCRIPTION:
PP Ball Feature: 1) Made of Polypropylene; 2) Plastic packing has the advantages of high void ratio, low pressure drop, low mass-transfer unit height, high flooding point, uniform gas-liquid contact, small specific gravity, high efficiency of mass transfer; 3) These various plastic tower packing are widely used in petroleum and chemical industries, alkali chloride industries, gas industries and environmental protection industries with max. Temperature of 150 degree centigrate.
WARRANTY:
a) By National Standard HG/T 21556.3-1995.
b) Offer lifetime consultation on problems occurred.
